GE
Chest Freezer

Model # CB22DMB Official GE chest freezer

Here are the diagrams and repair parts for Official GE CB22DMB chest freezer, as well as links to manuals and error code tables, if available.

There are a couple of ways to find the part or diagram you need:

  • Click a diagram to see the parts shown on that diagram.
  • In the search box below, enter all or part of the part number or the part’s name.

Not all parts are shown on the diagrams—those parts are labeled NI, for “not illustrated”.

We encourage you to save the model to your profile, so it’s easy to access parts and manuals for your appliance whenever you log in.

For DIY troubleshooting advice and repair guides, visit our repair help section.

Error Codes

Model diagram and schematic

SEARCH WITHIN THIS MODEL

?

This is the number corresponding to the part on the diagram / schematic

Search
ALL PARTS
Showing 10 of 33 parts  |
Dryer Assembly WR86X86
#46

Cabinet diagram

Dryer assembly

Part #WR86X86

Replaced by #WR86X25269

?
Manufacturer substitution
This part replaces WR86X86. Substitute parts can look different from the original.
BEST SELLER
$79.18 |
7% OFF Phone Price : $85.18
In Stock
Power Cord WR23X108
#626

Cabinet diagram

Power cord

Part #WR23X108

Replaced by #WR23X10300

?
Manufacturer substitution
This part replaces WR23X108. Substitute parts can look different from the original.
$22.68 |
21% OFF Phone Price : $28.68
In Stock
Clip WR1X5615
#59

Cabinet diagram

Clip

Part #WR1X5615

The manufacturer no longer makes this part, and there's no substitute part

Inner Lid Kt WR77X5690
#10

Cabinet diagram

Inner lid kt

Part #WR77X5690

The manufacturer no longer makes this part, and there's no substitute part

O D Panel Wh WR78X8200
#1

Cabinet diagram

O d panel wh

Part #WR78X8200

The manufacturer no longer makes this part, and there's no substitute part

Socket WR23X5148
#11

Cabinet diagram

Socket

Part #WR23X5148

The manufacturer no longer makes this part, and there's no substitute part

Drain Cap WR2X7457
#47

Cabinet diagram

Drain cap

Part #WR2X7457

The manufacturer no longer makes this part, and there's no substitute part

Buzzer WR23X5147
#57

Cabinet diagram

Buzzer

Part #WR23X5147

The manufacturer no longer makes this part, and there's no substitute part

Hinge Screw WR1X5616
#30

Cabinet diagram

Hinge screw

Part #WR1X5616

The manufacturer no longer makes this part, and there's no substitute part

Grommet WR2X7461
#58

Cabinet diagram

Grommet

Part #WR2X7461

The manufacturer no longer makes this part, and there's no substitute part
