Model # LMXS28626S/00 Official LG bottom

Here are the diagrams and repair parts for Official LG LMXS28626S-00 bottom, as well as links to manuals and error code tables, if available.

There are a couple of ways to find the part or diagram you need:

  • Click a diagram to see the parts shown on that diagram.
  • In the search box below, enter all or part of the part number or the part’s name.

Not all parts are shown on the diagrams—those parts are labeled NI, for “not illustrated”.

We encourage you to save the model to your profile, so it’s easy to access parts and manuals for your appliance whenever you log in.

For DIY troubleshooting advice and repair guides, visit our repair help section.

Owner’s manual
Error Codes

Model diagram and schematic

SEARCH WITHIN THIS MODEL

?

This is the number corresponding to the part on the diagram / schematic

Search
ALL PARTS
Showing 10 of 157 parts  |
Lg Lt1000p Refrigerator Water Filter ADQ74793501

#624A

All parts diagram

Lg lt1000p refrigerator water filter

Part #ADQ74793501

Replaced by #AGF80300704

?
Manufacturer substitution
This part replaces ADQ74793501. Substitute parts can look different from the original.
BEST SELLER

Get free shipping with Automatic Reorder

$66.99
In Stock
Refrigerator Door Flipper Mullion (agu75188619) - Refrigerator Electronic Component By Lg AGU75188619

#235A

All parts diagram

Refrigerator door flipper mullion (agu75188619) - refrigerator electronic component by lg

Part #AGU75188619

BEST SELLER
$120.82 |
9% OFF Phone Price : $132.82
In Stock
Refrigerator Ice Maker Assembly (replaces Aeq73110211) AEQ73110212

#600A

All parts diagram

Refrigerator ice maker assembly (replaces aeq73110211)

Part #AEQ73110212

Replaced by #AEQ73110210

?
Manufacturer substitution
This part replaces AEQ73110212. Substitute parts can look different from the original.
BEST SELLER
$166.25 |
7% OFF Phone Price : $178.25
In Stock
Refrigerator Dispenser Ice Chute Door Motor (replaces Eau59551201, Eau59551202, Eau59551203, Eau59551205, Eau59551207) EAU59551204

#405A

All parts diagram

Refrigerator dispenser ice chute door motor (replaces eau59551201, eau59551202, eau59551203, eau59551205, eau59551207)

Part #EAU59551204

BEST SELLER
$52.52 |
10% OFF Phone Price : $58.52
In Stock
Refrigerator Ice Maker And Auger Motor Assembly EAU61843016

#612A

All parts diagram

Refrigerator ice maker and auger motor assembly

Part #EAU61843016

Replaced by #EAU61843018

?
Manufacturer substitution
This part replaces EAU61843016. Substitute parts can look different from the original.
BEST SELLER
$165.01 |
7% OFF Phone Price : $177.01
In Stock
Refrigerator Water Inlet Valve (replaces 5221ja2011p, Aju72992606, Ebd60664501) AJU72992601

#619A

All parts diagram

Refrigerator water inlet valve (replaces 5221ja2011p, aju72992606, ebd60664501)

Part #AJU72992601

BEST SELLER
$111.69 |
10% OFF Phone Price : $123.69
In Stock
Refrigerator Ice Container Assembly AKC73249303

#611A

All parts diagram

Refrigerator ice container assembly

Part #AKC73249303

Replaced by #AKC73249304

?
Manufacturer substitution
This part replaces AKC73249303. Substitute parts can look different from the original.
BEST SELLER
$48.33 |
11% OFF Phone Price : $54.33
In Stock
Refrigerator Evaporator Cover Assembly AEB73764513

#332C

All parts diagram

Refrigerator evaporator cover assembly

Part #AEB73764513

Replaced by #AEB73764519

?
Manufacturer substitution
This part replaces AEB73764513. Substitute parts can look different from the original.
BEST SELLER
$140.05 |
8% OFF Phone Price : $152.05
In Stock
Refrigerator Water Inlet Valve (replaces 5221jb2010l, 5221jb2010q, 5221jb2010u) 5221JB2010G

#619B

All parts diagram

Refrigerator water inlet valve (replaces 5221jb2010l, 5221jb2010q, 5221jb2010u)

Part #5221JB2010G

BEST SELLER
$124.14 |
9% OFF Phone Price : $136.14
In Stock
Refrigerator Compressor Overload Protector 6750CL0001D

#303C

All parts diagram

Refrigerator compressor overload protector

Part #6750CL0001D

BEST SELLER
$26.29 |
19% OFF Phone Price : $32.29
In Stock

RECOMMENDED MAINTENANCE PARTS AND ACCESSORIES

Most common symptoms to help you fix your refrigerators

Choose a symptom to see related refrigerator repairs.

View all

Why won't my refrigerator run?

Main causes: control board or cold control failure, broken compressor start relay, compressor motor failure, defrost tim…

Read more

Why won't my refrigerator ice maker make ice?

Main causes: jammed ice cubes, broken ice maker assembly, dirty water filter, kinked water line, bad water valve, freeze…

Read more

Why is water dripping from my refrigerator onto the floor?

Main causes: water valve leaking, frozen or broken defrost drain tube, overflowing drain pan, cracked water system tubin…

Read more

Why is frost building up in my refrigerator's freezer?

Main causes: damaged door seal, faulty defrost sensor or bi-metal thermostat, broken defrost heater, bad defrost timer o…

Read more

Why isn't my refrigerator cooling well?

Main causes: blocked vents, defrost system problems, evaporator fan failure, dirty condenser coils, bad sensors, condens…

Read more

Why won't my refrigerator cool at all?

Main causes: blocked air vents, compressor problems, condenser or evaporator fan not working, control system failure, se…

Read more

Why is my freezer not cold enough?

Main causes: leaky door gasket, defrost system failure, evaporator fan not running, dirty condenser coils, condenser fan…

Read more

What routine maintenance does my refrigerator need?

Things to do: clean condenser coils, replace the water filter, clean the interior, adjust doors to prevent air leaks, cl…
