Kenmore
Household Fan

Model # 689930020 Official Kenmore ceiling fan accessory light kit

Here are the diagrams and repair parts for Official Kenmore 689930020 ceiling fan accessory light kit, as well as links to manuals and error code tables, if available.

There are a couple of ways to find the part or diagram you need:

  • Click a diagram to see the parts shown on that diagram.
  • In the search box below, enter all or part of the part number or the part’s name.

Not all parts are shown on the diagrams—those parts are labeled NI, for “not illustrated”.

We encourage you to save the model to your profile, so it’s easy to access parts and manuals for your appliance whenever you log in.

For DIY troubleshooting advice and repair guides, visit our repair help section.

Model diagram and schematic

SEARCH WITHIN THIS MODEL

?

This is the number corresponding to the part on the diagram / schematic

Search
ALL PARTS
Showing 9 of 9 parts  |
Shade Glass RGS100
#1A

Accessory diagram

Shade glass

Part #RGS100

The manufacturer no longer makes this part, and there's no substitute part

3-speed Switch N/P
3-speed switch

Part #N/P

The manufacturer no longer makes this part, and there's no substitute part

Pull Switch PCS100
#4

Accessory diagram

Pull switch

Part #PCS100

The manufacturer no longer makes this part, and there's no substitute part

Glass Globe 11-008
#1B

Accessory diagram

Glass globe

Part #11-008

The manufacturer no longer makes this part, and there's no substitute part

Screw AKS100
#3B

Accessory diagram

Screw

Part #AKS100

The manufacturer no longer makes this part, and there's no substitute part

Cover PTU3020
#2A

Accessory diagram

Cover

Part #PTU3020

The manufacturer no longer makes this part, and there's no substitute part

Screw PKS100
#3A

Accessory diagram

Screw

Part #PKS100

The manufacturer no longer makes this part, and there's no substitute part

Cover ATU3020
#2B

Accessory diagram

Cover

Part #ATU3020

The manufacturer no longer makes this part, and there's no substitute part

Owner's Manual SVLK101

#NI

All parts diagram

Owner's manual

Part #SVLK101

The manufacturer no longer makes this part, and there's no substitute part
