Model # WR87X0260 Official GE refrigerator
Here are the diagrams and repair parts for Official GE WR87X0260 refrigerator, as well as links to manuals and error code tables, if available.
Error CodesBy Schematic
By Part
SELECT DIAGRAM
Browse Parts for
WR87X0260 Refrigerators
#740
All parts diagram
Dryer assembly
Part #WR86X86
Replaced by #WR86X25269
?
Manufacturer substitution
This part replaces WR86X86. Substitute parts can look different from the original.
$78.01 |
7% OFF Phone Price : $84.01
In Stock
#650
All parts diagram
Refrigerator condenser fan motor
Part #WR60X179
Replaced by #WR60X187
?
Manufacturer substitution
This part replaces WR60X179. Substitute parts can look different from the original.
$254.46 |
5% OFF Phone Price : $266.46
In Stock
#725
All parts diagram
Refrigerator compressor
Part #WR87X238
Replaced by #WR87X10082
?
Manufacturer substitution
This part replaces WR87X238. Substitute parts can look different from the original.
$747.03 |
$12.00 OFF Phone Price : $759.03
In Stock
#602
All parts diagram
Screw
Part #WR1X1591
This item is not returnable
$7.40 |
12% OFF Phone Price : $8.40
In Stock
#762
All parts diagram
Refrigerator evaporator cover seal
Part #WR14X313
$19.73 |
9% OFF Phone Price : $21.73
In Stock
#737
All parts diagram
Refrigerator compressor mounting post
Part #WR1X1779
$8.06 |
11% OFF Phone Price : $9.06
In Stock
#750
All parts diagram
Refrigerator screw
Part #WR1X1781
Replaced by #WR1X1786
?
Manufacturer substitution
This part replaces WR1X1781. Substitute parts can look different from the original.
$8.37 |
11% OFF Phone Price : $9.37
In Stock
#729
All parts diagram
Refrigerator capacitor
Part #WR62X50
Replaced by #WR55X24065
?
Manufacturer substitution
This part replaces WR62X50. Substitute parts can look different from the original.
$50.06 |
11% OFF Phone Price : $56.06
In Stock
#627
All parts diagram
Refrigerator baffle
Part #WR17X1488
The manufacturer no longer makes this part, and there's no substitute part
#651
All parts diagram
Refrigerator nut
Part #WR1X1515
The manufacturer no longer makes this part, and there's no substitute part
