Top-Mount Refrigerator

Model # TBT24JAXBRAA Official GE top-mount refrigerator - 1995 tropical line

Here are the diagrams and repair parts for Official GE TBT24JAXBRAA top-mount refrigerator - 1995 tropical line, as well as links to manuals and error code tables, if available.

There are a couple of ways to find the part or diagram you need:

  • Click a diagram to see the parts shown on that diagram.
  • In the search box below, enter all or part of the part number or the part’s name.

Not all parts are shown on the diagrams—those parts are labeled NI, for “not illustrated”.

We encourage you to save the model to your profile, so it’s easy to access parts and manuals for your appliance whenever you log in.

For DIY troubleshooting advice and repair guides, visit our repair help section.

Error Codes

Model diagram and schematic

SEARCH WITHIN THIS MODEL

?

This is the number corresponding to the part on the diagram / schematic

Search
ALL PARTS
Showing 10 of 219 parts  |
Refrigerator Filter Dryer WR86X96

#740

All parts diagram

Refrigerator filter dryer

Part #WR86X96

Replaced by #WR86X25269

?
Manufacturer substitution
This part replaces WR86X96. Substitute parts can look different from the original.
BEST SELLER
$79.18 |
7% OFF Phone Price : $85.18
In Stock
40a15/22 STD372402

#435

All parts diagram

40a15/22

Part #STD372402

Replaced by #40A15

?
Manufacturer substitution
This part replaces STD372402. Substitute parts can look different from the original.
BEST SELLER
$15.16 |
12% OFF Phone Price : $17.16
In Stock
Refrigerator Door Gasket (white) (replaces Swr24x437, Wr24x0437) WR24X437

#104

All parts diagram

Refrigerator door gasket (white) (replaces swr24x437, wr24x0437)

Part #WR24X437

$65.79 |
8% OFF Phone Price : $71.79
In Stock
Light Switch WR23X193

#609

All parts diagram

Light switch

Part #WR23X193

Replaced by #WR23X37285

?
Manufacturer substitution
This part replaces WR23X193. Substitute parts can look different from the original.
$8.11
In Stock
Power Cord WR23X108

#626

All parts diagram

Power cord

Part #WR23X108

Replaced by #WR23X10300

?
Manufacturer substitution
This part replaces WR23X108. Substitute parts can look different from the original.
$22.68 |
21% OFF Phone Price : $28.68
In Stock
Refrigerator Defrost Heater WR51X423

#618

All parts diagram

Refrigerator defrost heater

Part #WR51X423

Replaced by #WR51X466

?
Manufacturer substitution
This part replaces WR51X423. Substitute parts can look different from the original.
$212.27 |
5% OFF Phone Price : $224.27
In Stock
Refrigerator Door Hole Plug (white) WR2X8693

#112

All parts diagram

Refrigerator door hole plug (white)

Part #WR2X8693

Replaced by #WR01X21159

?
Manufacturer substitution
This part replaces WR2X8693. Substitute parts can look different from the original.
This item is not returnable
$7.88 |
11% OFF Phone Price : $8.88
In Stock
Refrigerator Roller WR2X3594

#264

All parts diagram

Refrigerator roller

Part #WR2X3594

This item is not returnable
$21.62 |
22% OFF Phone Price : $27.62
In Stock
Refrigerator Evaporator Cover Seal WR14X313

#762

All parts diagram

Refrigerator evaporator cover seal

Part #WR14X313

$17.31 |
10% OFF Phone Price : $19.31
In Stock
Washer, 12-pack WR1X1797

#281

All parts diagram

Washer, 12-pack

Part #WR1X1797

Replaced by #WR1X1797D

?
Manufacturer substitution
This part replaces WR1X1797. Substitute parts can look different from the original.
$23.67 |
20% OFF Phone Price : $29.67
In Stock
