Amana
Electric Wall Oven

Model # AO-24BT-P85023-1S Official Amana range

Here are the diagrams and repair parts for Official Amana AO-24BT-P85023-1S range, as well as links to manuals and error code tables, if available.

There are a couple of ways to find the part or diagram you need:

  • Click a diagram to see the parts shown on that diagram.
  • In the search box below, enter all or part of the part number or the part’s name.

Not all parts are shown on the diagrams—those parts are labeled NI, for “not illustrated”.

We encourage you to save the model to your profile, so it’s easy to access parts and manuals for your appliance whenever you log in.

For DIY troubleshooting advice and repair guides, visit our repair help section.

Model diagram and schematic

SEARCH WITHIN THIS MODEL

?

This is the number corresponding to the part on the diagram / schematic

Search
ALL PARTS
Showing 10 of 145 parts  |

Hi-limit Thermostat CG971771

#NI

All parts diagram

Hi-limit thermostat

Part #CG971771

The manufacturer no longer makes this part, and there's no substitute part

Switch CG981798
Switch

Part #CG981798

The manufacturer no longer makes this part, and there's no substitute part

Cotter Key CG981869
Cotter key

Part #CG981869

The manufacturer no longer makes this part, and there's no substitute part

Oven Broiler Pan CG981879
Oven broiler pan

Part #CG981879

The manufacturer no longer makes this part, and there's no substitute part

Lock Nut CG981845
Lock nut

Part #CG981845

The manufacturer no longer makes this part, and there's no substitute part

No. 5-40 X 1 Screw CG981829
No. 5-40 x 1 screw

Part #CG981829

The manufacturer no longer makes this part, and there's no substitute part

Panel Light CG080124
Panel light

Part #CG080124

The manufacturer no longer makes this part, and there's no substitute part

Installation Instructions CG080118

#NI

All parts diagram

Installation instructions

Part #CG080118

The manufacturer no longer makes this part, and there's no substitute part

Vent Extrusion CG981773
Vent extrusion

Part #CG981773

The manufacturer no longer makes this part, and there's no substitute part

Bottom Trim (includes Cg984546 And Caps And Cg984547 Mou CG983889
Bottom trim (includes cg984546 and caps and cg984547 mou

Part #CG983889

The manufacturer no longer makes this part, and there's no substitute part
