Gladiator
Tool Cabinet

Model # GATB30PLVG00 Official Gladiator proline garage works

Here are the diagrams and repair parts for Official Gladiator GATB30PLVG00 proline garage works, as well as links to manuals and error code tables, if available.

There are a couple of ways to find the part or diagram you need:

  • Click a diagram to see the parts shown on that diagram.
  • In the search box below, enter all or part of the part number or the part’s name.

Not all parts are shown on the diagrams—those parts are labeled NI, for “not illustrated”.

We encourage you to save the model to your profile, so it’s easy to access parts and manuals for your appliance whenever you log in.

For DIY troubleshooting advice and repair guides, visit our repair help section.

Model diagram and schematic

SEARCH WITHIN THIS MODEL

?

This is the number corresponding to the part on the diagram / schematic

Search
ALL PARTS
Showing 10 of 19 parts  |
Door 8211219
#17

Tall gearbox parts diagram

Door

Part #8211219

$407.40
In Stock
Catch-door 8204648
#10

Tall gearbox parts diagram

Catch-door

Part #8204648

Replaced by #W11369680

?
Manufacturer substitution
This part replaces 8204648. Substitute parts can look different from the original.
$25.79 |
19% OFF Phone Price : $31.79
In Stock
Caster 8204602
#2

Tall gearbox parts diagram

Caster

Part #8204602

Replaced by #WP8204602

?
Manufacturer substitution
This part replaces 8204602. Substitute parts can look different from the original.
$54.86
In Stock
Nylon Nut 8204610
#4

Tall gearbox parts diagram

Nylon nut

Part #8204610

Replaced by #WP8204610

?
Manufacturer substitution
This part replaces 8204610. Substitute parts can look different from the original.
$12.49
In Stock
Caster 8204601
#1

Tall gearbox parts diagram

Caster

Part #8204601

Replaced by #WP8204601

?
Manufacturer substitution
This part replaces 8204601. Substitute parts can look different from the original.
$37.92
In Stock
Tool Chest Key, 2-pack 8204608
#8

Tall gearbox parts diagram

Tool chest key, 2-pack

Part #8204608

Replaced by #W11383363

?
Manufacturer substitution
This part replaces 8204608. Substitute parts can look different from the original.
This item is not returnable
$4.26 |
19% OFF Phone Price : $5.26
Back Order
Bolt 8204609
#3

Tall gearbox parts diagram

Bolt

Part #8204609

Replaced by #WP8204609

?
Manufacturer substitution
This part replaces 8204609. Substitute parts can look different from the original.
$22.65
In Stock
Nameplate W10238957
#6

Tall gearbox parts diagram

Nameplate

Part #W10238957

The manufacturer no longer makes this part, and there's no substitute part

Door Handle W10238968
#5

Tall gearbox parts diagram

Door handle

Part #W10238968

The manufacturer no longer makes this part, and there's no substitute part

Door 8211220
#18

Tall gearbox parts diagram

Door

Part #8211220

The manufacturer no longer makes this part, and there's no substitute part
