Model # CKD7242819A Official Hardwick gas range

Here are the diagrams and repair parts for Official Hardwick CKD7242819A gas range, as well as links to manuals and error code tables, if available.

There are a couple of ways to find the part or diagram you need:

  • Click a diagram to see the parts shown on that diagram.
  • In the search box below, enter all or part of the part number or the part’s name.

Not all parts are shown on the diagrams—those parts are labeled NI, for “not illustrated”.

We encourage you to save the model to your profile, so it’s easy to access parts and manuals for your appliance whenever you log in.

For DIY troubleshooting advice and repair guides, visit our repair help section.

Error Codes

Model diagram and schematic

SEARCH WITHIN THIS MODEL

?

This is the number corresponding to the part on the diagram / schematic

Search
ALL PARTS
Showing 10 of 63 parts  |
Broiler Pan 9G06400453
#41

Body diagram

Broiler pan

Part #9G06400453

Replaced by #4396923

?
Manufacturer substitution
This part replaces 9G06400453. Substitute parts can look different from the original.
$29.55 |
17% OFF Phone Price : $35.55
In Stock
Broiler Tray 9G06700453
#68

Body diagram

Broiler tray

Part #9G06700453

Replaced by #4396923

?
Manufacturer substitution
This part replaces 9G06700453. Substitute parts can look different from the original.
$29.55 |
17% OFF Phone Price : $35.55
In Stock
Oven Support 7G12501541
#60

Body diagram

Oven support

Part #7G12501541

The manufacturer no longer makes this part, and there's no substitute part

Oven Rack 0R01001811
#48

Body diagram

Oven rack

Part #0R01001811

The manufacturer no longer makes this part, and there's no substitute part

Light Tubing 9G19103416
#76

Body diagram

Light tubing

Part #9G19103416

The manufacturer no longer makes this part, and there's no substitute part

Oven Valve 0V03430499
#78

Body diagram

Oven valve

Part #0V03430499

The manufacturer no longer makes this part, and there's no substitute part

Base, Main A 7G10202841
#5

Body diagram

Base, main a

Part #7G10202841

The manufacturer no longer makes this part, and there's no substitute part

Regulator P 0R00301416
#49A

Body diagram

Regulator p

Part #0R00301416

The manufacturer no longer makes this part, and there's no substitute part

"t" Fitting (flange) N/P
"t" fitting (flange)

Part #N/P

The manufacturer no longer makes this part, and there's no substitute part

Oven Glass 0G00109499
#6

Door (glass) (ckd7241819a) diagram

Oven glass

Part #0G00109499

The manufacturer no longer makes this part, and there's no substitute part
