Carrier
Central Air Conditioner

Model # 38BYG048 SERIES300 Official Carrier heat pump

Here are the diagrams and repair parts for Official Carrier 38BYG048-SERIES300 heat pump, as well as links to manuals and error code tables, if available.

There are a couple of ways to find the part or diagram you need:

  • Click a diagram to see the parts shown on that diagram.
  • In the search box below, enter all or part of the part number or the part’s name.

Not all parts are shown on the diagrams—those parts are labeled NI, for “not illustrated”.

We encourage you to save the model to your profile, so it’s easy to access parts and manuals for your appliance whenever you log in.

For DIY troubleshooting advice and repair guides, visit our repair help section.

Model diagram and schematic

SEARCH WITHIN THIS MODEL

?

This is the number corresponding to the part on the diagram / schematic

Search
ALL PARTS
Showing 10 of 125 parts  |

Cntrl Baord HK32EA001

#32

All parts diagram

Cntrl baord

Part #HK32EA001

In Stock
Strap Cap 317739-303

#30

All parts diagram

Strap cap

Part #317739-303

In Stock
Sw Adapter 313973-201

#133

All parts diagram

Sw adapter

Part #313973-201

In Stock
Cap 317759-201

#78

All parts diagram

Cap

Part #317759-201

In Stock
Payne Harness 317497-701

#28

All parts diagram

Payne harness

Part #317497-701

In Stock
Heater P041-4443

#108

All parts diagram

Heater

Part #P041-4443

In Stock
Capac Dual P291-6074R

#31

All parts diagram

Capac dual

Part #P291-6074R

In Stock
Central Air Conditioner Compressor Hard Start Kit KSAHS1701AAA

#128

All parts diagram

Central air conditioner compressor hard start kit

Part #KSAHS1701AAA

$324.46
$12.00 OFF Phone Price : $336.46
In Stock
Payne Trans HT01AW229

#112

All parts diagram

Payne trans

Part #HT01AW229

In Stock
Piston Ret 319073-201

#147

All parts diagram

Piston ret

Part #319073-201

In Stock
