Model # 165155184 Official Craftsman airless paint sprayer

Here are the diagrams and repair parts for Official Craftsman 165155184 airless paint sprayer, as well as links to manuals and error code tables, if available.

There are a couple of ways to find the part or diagram you need:

  • Click a diagram to see the parts shown on that diagram.
  • In the search box below, enter all or part of the part number or the part’s name.

Not all parts are shown on the diagrams—those parts are labeled NI, for “not illustrated”.

We encourage you to save the model to your profile, so it’s easy to access parts and manuals for your appliance whenever you log in.

For DIY troubleshooting advice and repair guides, visit our repair help section.

Model diagram and schematic

SEARCH WITHIN THIS MODEL

?

This is the number corresponding to the part on the diagram / schematic

Search
ALL PARTS
Showing 10 of 45 parts  |
Fan Nozzle 30-16318
#38

Replacement parts diagram

Fan nozzle

Part #30-16318

The manufacturer no longer makes this part, and there's no substitute part

Flex Body 89429
#36

Replacement parts diagram

Flex body

Part #89429

The manufacturer no longer makes this part, and there's no substitute part

Container 88544
#31

Replacement parts diagram

Container

Part #88544

The manufacturer no longer makes this part, and there's no substitute part

Nozzle 30-16313
#35

Replacement parts diagram

Nozzle

Part #30-16313

The manufacturer no longer makes this part, and there's no substitute part

Armature 45311
#10

Replacement parts diagram

Armature

Part #45311

The manufacturer no longer makes this part, and there's no substitute part

Screw No 6 89506
#27

Replacement parts diagram

Screw no 6

Part #89506

The manufacturer no longer makes this part, and there's no substitute part

Extension Cord 34-7797

#NI

All parts diagram

Extension cord

Part #34-7797

The manufacturer no longer makes this part, and there's no substitute part

Lug 89539
#28

Replacement parts diagram

Lug

Part #89539

The manufacturer no longer makes this part, and there's no substitute part

Piston 31315
#6

Replacement parts diagram

Piston

Part #31315

The manufacturer no longer makes this part, and there's no substitute part

Owner's Manual 501052-10/79A

#NI

All parts diagram

Owner's manual

Part #501052-10/79A

The manufacturer no longer makes this part, and there's no substitute part
