Electric Wall Oven

Model # HBN5420/02 Official Bosch electric built-in oven

Here are the diagrams and repair parts for Official Bosch HBN5420-02 electric built-in oven, as well as links to manuals and error code tables, if available.

There are a couple of ways to find the part or diagram you need:

  • Click a diagram to see the parts shown on that diagram.
  • In the search box below, enter all or part of the part number or the part’s name.

Not all parts are shown on the diagrams—those parts are labeled NI, for “not illustrated”.

We encourage you to save the model to your profile, so it’s easy to access parts and manuals for your appliance whenever you log in.

For DIY troubleshooting advice and repair guides, visit our repair help section.

Error Codes

Model diagram and schematic

SEARCH WITHIN THIS MODEL

?

This is the number corresponding to the part on the diagram / schematic

Search
ALL PARTS
Showing 10 of 84 parts  |
Sticker 519252

#519252

All parts diagram

Sticker

Part #519252

Replaced by #00633848

?
Manufacturer substitution
This part replaces 519252. Substitute parts can look different from the original.
$55.24
In Stock
Glass Panel 356612

#356612

All parts diagram

Glass panel

Part #356612

The manufacturer no longer makes this part, and there's no substitute part

Rail 284915

#284915

All parts diagram

Rail

Part #284915

The manufacturer no longer makes this part, and there's no substitute part

Instruction Manual 528212

#528212

All parts diagram

Instruction manual

Part #528212

The manufacturer no longer makes this part, and there's no substitute part

Lamp Housing 173950

#173950

All parts diagram

Lamp housing

Part #173950

The manufacturer no longer makes this part, and there's no substitute part

Oven Frying Pan 284917

#284917

All parts diagram

Oven frying pan

Part #284917

The manufacturer no longer makes this part, and there's no substitute part

Panel-fascia 361173

#361173

All parts diagram

Panel-fascia

Part #361173

The manufacturer no longer makes this part, and there's no substitute part

Limiter-temperature 173651

#173651

All parts diagram

Limiter-temperature

Part #173651

The manufacturer no longer makes this part, and there's no substitute part

Strip 356536

#356536

All parts diagram

Strip

Part #356536

The manufacturer no longer makes this part, and there's no substitute part

Screw 173588

#173588

All parts diagram

Screw

Part #173588

The manufacturer no longer makes this part, and there's no substitute part
