Model # TCX22ZRBRWH Official GE bottom-mount refrigerator

Here are the diagrams and repair parts for Official GE TCX22ZRBRWH bottom-mount refrigerator, as well as links to manuals and error code tables, if available.

There are a couple of ways to find the part or diagram you need:

  • Click a diagram to see the parts shown on that diagram.
  • In the search box below, enter all or part of the part number or the part’s name.

Not all parts are shown on the diagrams—those parts are labeled NI, for “not illustrated”.

We encourage you to save the model to your profile, so it’s easy to access parts and manuals for your appliance whenever you log in.

For DIY troubleshooting advice and repair guides, visit our repair help section.

Error Codes

Model diagram and schematic

SEARCH WITHIN THIS MODEL

?

This is the number corresponding to the part on the diagram / schematic

Search
ALL PARTS
Showing 10 of 213 parts  |
Drier WR86X83

#740

All parts diagram

Drier

Part #WR86X83

Replaced by #WR86X25269

?
Manufacturer substitution
This part replaces WR86X83. Substitute parts can look different from the original.
BEST SELLER
$79.18 |
7% OFF Phone Price : $85.18
In Stock
Refrigerator Defrost Control WR9X466

#19

All parts diagram

Refrigerator defrost control

Part #WR9X466

Replaced by #WR9X483

?
Manufacturer substitution
This part replaces WR9X466. Substitute parts can look different from the original.
BEST SELLER
$42.02 |
12% OFF Phone Price : $48.02
In Stock
Refrigerator Light Switch WR23X5142

#3

All parts diagram

Refrigerator light switch

Part #WR23X5142

Replaced by #WR23X37285

?
Manufacturer substitution
This part replaces WR23X5142. Substitute parts can look different from the original.
$8.11
In Stock
Power Cord WR23X108

#626

All parts diagram

Power cord

Part #WR23X108

Replaced by #WR23X10300

?
Manufacturer substitution
This part replaces WR23X108. Substitute parts can look different from the original.
$22.68 |
21% OFF Phone Price : $28.68
In Stock
Refrigerator Screw WR1X5684

#12

All parts diagram

Refrigerator screw

Part #WR1X5684

This item is not returnable
$4.35
In Stock
Str Relief WR2X3736

#805

All parts diagram

Str relief

Part #WR2X3736

Replaced by #WR1X5278

?
Manufacturer substitution
This part replaces WR2X3736. Substitute parts can look different from the original.
$7.57 |
12% OFF Phone Price : $8.57
In Stock
Refrigerator Capacitor WR62X5013

#39

All parts diagram

Refrigerator capacitor

Part #WR62X5013

Replaced by #WR60X25785

?
Manufacturer substitution
This part replaces WR62X5013. Substitute parts can look different from the original.
This item is not returnable
$18.29 |
10% OFF Phone Price : $20.29
In Stock
Refrigerator Screw WR1X5593

#40

All parts diagram

Refrigerator screw

Part #WR1X5593

Replaced by #WE02X10011

?
Manufacturer substitution
This part replaces WR1X5593. Substitute parts can look different from the original.
$23.71
In Stock
Refrigerator Ice Tray WR30X196

#213

All parts diagram

Refrigerator ice tray

Part #WR30X196

Replaced by #WR30X311

?
Manufacturer substitution
This part replaces WR30X196. Substitute parts can look different from the original.
This item is not returnable
$7.88 |
11% OFF Phone Price : $8.88
In Stock
Lo-side WR85X220

#10

All parts diagram

Lo-side

Part #WR85X220

The manufacturer no longer makes this part, and there's no substitute part
