Skil
Hammer Drill

Model # 731 TYPE 1 Official Skil 731 heavy-duty roto-hammer-type 1

Here are the diagrams and repair parts for Official Skil 731-TYPE-1 731 heavy-duty roto-hammer-type 1, as well as links to manuals and error code tables, if available.

There are a couple of ways to find the part or diagram you need:

  • Click a diagram to see the parts shown on that diagram.
  • In the search box below, enter all or part of the part number or the part’s name.

Not all parts are shown on the diagrams—those parts are labeled NI, for “not illustrated”.

We encourage you to save the model to your profile, so it’s easy to access parts and manuals for your appliance whenever you log in.

For DIY troubleshooting advice and repair guides, visit our repair help section.

Model diagram and schematic

SEARCH WITHIN THIS MODEL

?

This is the number corresponding to the part on the diagram / schematic

Search
ALL PARTS
Showing 10 of 103 parts  |
Skil Felt Seal 25528

#13

All parts diagram

Skil felt seal

Part #25528

The manufacturer no longer makes this part, and there's no substitute part

Skil Housing 308996

#94

All parts diagram

Skil housing

Part #308996

The manufacturer no longer makes this part, and there's no substitute part

Pin 302091

#1

All parts diagram

Pin

Part #302091

The manufacturer no longer makes this part, and there's no substitute part

Skil Washer 68577

#3

All parts diagram

Skil washer

Part #68577

The manufacturer no longer makes this part, and there's no substitute part

Skil Top Plate 308984

#66

All parts diagram

Skil top plate

Part #308984

The manufacturer no longer makes this part, and there's no substitute part

Screw 29360

#12

All parts diagram

Screw

Part #29360

The manufacturer no longer makes this part, and there's no substitute part

Skil Spring 304084

#21

All parts diagram

Skil spring

Part #304084

The manufacturer no longer makes this part, and there's no substitute part

Skil Retainer 302095

#4

All parts diagram

Skil retainer

Part #302095

The manufacturer no longer makes this part, and there's no substitute part

Skil Screw 26370

#10

All parts diagram

Skil screw

Part #26370

The manufacturer no longer makes this part, and there's no substitute part

Skil Screw 305955

#84

All parts diagram

Skil screw

Part #305955

The manufacturer no longer makes this part, and there's no substitute part
