Kenmore
Bottom-Mount Refrigerator

Model # 79571022016 Official Kenmore bottom-mount refrigerator

Here are the diagrams and repair parts for Official Kenmore 79571022016 bottom-mount refrigerator, as well as links to manuals and error code tables, if available.

There are a couple of ways to find the part or diagram you need:

  • Click a diagram to see the parts shown on that diagram.
  • In the search box below, enter all or part of the part number or the part’s name.

Not all parts are shown on the diagrams—those parts are labeled NI, for “not illustrated”.

We encourage you to save the model to your profile, so it’s easy to access parts and manuals for your appliance whenever you log in.

For DIY troubleshooting advice and repair guides, visit our repair help section.

Error Codes

Model diagram and schematic

SEARCH WITHIN THIS MODEL

?

This is the number corresponding to the part on the diagram / schematic

Search
ALL PARTS
Showing 10 of 211 parts  |
Refrigerator Filter Dryer 5851JA2007E

#317A

All parts diagram

Refrigerator filter dryer

Part #5851JA2007E

Replaced by #ADH73150210

?
Manufacturer substitution
This part replaces 5851JA2007E. Substitute parts can look different from the original.
BEST SELLER
$67.13 |
8% OFF Phone Price : $73.13
In Stock
Kenmore Refrigerator Water Filter 9990 (replaces Cls30320001) 5231JA2006E

#624A

All parts diagram

Kenmore refrigerator water filter 9990 (replaces cls30320001)

Part #5231JA2006E

BEST SELLER

Get free shipping with Automatic Reorder

$54.99
In Stock
Refrigerator Door Switch 6600JB1010K

#406B

All parts diagram

Refrigerator door switch

Part #6600JB1010K

Replaced by #6600JB1010A

?
Manufacturer substitution
This part replaces 6600JB1010K. Substitute parts can look different from the original.
BEST SELLER
$22.36 |
21% OFF Phone Price : $28.36
In Stock
Refrigerator Compressor TCA34649901

#300A

All parts diagram

Refrigerator compressor

Part #TCA34649901

Replaced by #TCA36411702

?
Manufacturer substitution
This part replaces TCA34649901. Substitute parts can look different from the original.
BEST SELLER
$407.94 |
$12.00 OFF Phone Price : $419.94
In Stock
Refrigerator Freezer Door Gasket MDS38201401

#203A

All parts diagram

Refrigerator freezer door gasket

Part #MDS38201401

Replaced by #MDS38201426

?
Manufacturer substitution
This part replaces MDS38201401. Substitute parts can look different from the original.
BEST SELLER
$54.15 |
10% OFF Phone Price : $60.15
In Stock
Refrigerator Water Inlet Valve (replaces 5221ja2011j) MJX41178908

#619A

All parts diagram

Refrigerator water inlet valve (replaces 5221ja2011j)

Part #MJX41178908

BEST SELLER
$42.47 |
12% OFF Phone Price : $48.47
In Stock
Refrigerator Temperature Sensor And Cover ACQ73244001

#610C

All parts diagram

Refrigerator temperature sensor and cover

Part #ACQ73244001

BEST SELLER
$26.27 |
19% OFF Phone Price : $32.27
In Stock
Refrigerator Door Basket AAP36817401

#241D

All parts diagram

Refrigerator door basket

Part #AAP36817401

Replaced by #AAP73871501

?
Manufacturer substitution
This part replaces AAP36817401. Substitute parts can look different from the original.
BEST SELLER
$32.96 |
15% OFF Phone Price : $38.96
In Stock
Refrigerator Tray AJP36700901

#145D

All parts diagram

Refrigerator tray

Part #AJP36700901

Replaced by #AJP73874601

?
Manufacturer substitution
This part replaces AJP36700901. Substitute parts can look different from the original.
BEST SELLER
$77.34 |
7% OFF Phone Price : $83.34
In Stock
Refrigerator Defrost Sensor Assembly (replaces 6007ja3006r, 6615jb2005m) 6615JB2005H

#400A

All parts diagram

Refrigerator defrost sensor assembly (replaces 6007ja3006r, 6615jb2005m)

Part #6615JB2005H

BEST SELLER
$22.07 |
21% OFF Phone Price : $28.07
In Stock
