Kenmore
Water Heater

Model # 220339600 Official Kenmore gas water heater

Here are the diagrams and repair parts for Official Kenmore 220339600 gas water heater, as well as links to manuals and error code tables, if available.

There are a couple of ways to find the part or diagram you need:

  • Click a diagram to see the parts shown on that diagram.
  • In the search box below, enter all or part of the part number or the part’s name.

Not all parts are shown on the diagrams—those parts are labeled NI, for “not illustrated”.

We encourage you to save the model to your profile, so it’s easy to access parts and manuals for your appliance whenever you log in.

For DIY troubleshooting advice and repair guides, visit our repair help section.

Error Codes

Model diagram and schematic

SEARCH WITHIN THIS MODEL

?

This is the number corresponding to the part on the diagram / schematic

Search
ALL PARTS
Showing 10 of 22 parts  |
Dip Tube AS21064H
#16

Replacement parts diagram

Dip tube

Part #AS21064H

Replaced by #SP11248R

?
Manufacturer substitution
This part replaces AS21064H. Substitute parts can look different from the original.
$24.44
In Stock
Burner AS29458AB
#6

Replacement parts diagram

Burner

Part #AS29458AB

Replaced by #AM35050EFF

?
Manufacturer substitution
This part replaces AS29458AB. Substitute parts can look different from the original.
$130.28 |
8% OFF Phone Price : $142.28
In Stock
Anode AS36255AC
#14

Replacement parts diagram

Anode

Part #AS36255AC

Replaced by #SP11526C

?
Manufacturer substitution
This part replaces AS36255AC. Substitute parts can look different from the original.
$60.14 |
9% OFF Phone Price : $66.14
In Stock
Door AS29501
#11

Replacement parts diagram

Door

Part #AS29501

Replaced by #AS29501-3

?
Manufacturer substitution
This part replaces AS29501. Substitute parts can look different from the original.
This item is not returnable
$24.09 |
20% OFF Phone Price : $30.09
In Stock
Thermostat AP8855B
#1

Replacement parts diagram

Thermostat

Part #AP8855B

Replaced by #SP20164

?
Manufacturer substitution
This part replaces AP8855B. Substitute parts can look different from the original.
$166.39 |
7% OFF Phone Price : $178.39
In Stock
Burner AP8980B
#7

Replacement parts diagram

Burner

Part #AP8980B

Replaced by #SP8980C

?
Manufacturer substitution
This part replaces AP8980B. Substitute parts can look different from the original.
$37.60
In Stock
Collar AS20657
#13

Replacement parts diagram

Collar

Part #AS20657

Replaced by #AM20657

?
Manufacturer substitution
This part replaces AS20657. Substitute parts can look different from the original.
$18.54
In Stock
Drain Valve AP10424B
#9

Replacement parts diagram

Drain valve

Part #AP10424B

Replaced by #100108605

?
Manufacturer substitution
This part replaces AP10424B. Substitute parts can look different from the original.
$27.78
In Stock
Relief Valve AP6571B
#18

Replacement parts diagram

Relief valve

Part #AP6571B

The manufacturer no longer makes this part, and there's no substitute part

Hanger AS20622C
#12A

Replacement parts diagram

Hanger

Part #AS20622C

The manufacturer no longer makes this part, and there's no substitute part
