Samsung
Home Theater System

Model # HT-DB390 Official Samsung dvd player

Here are the diagrams and repair parts for Official Samsung HT-DB390 dvd player, as well as links to manuals and error code tables, if available.

There are a couple of ways to find the part or diagram you need:

  • Click a diagram to see the parts shown on that diagram.
  • In the search box below, enter all or part of the part number or the part’s name.

Not all parts are shown on the diagrams—those parts are labeled NI, for “not illustrated”.

We encourage you to save the model to your profile, so it’s easy to access parts and manuals for your appliance whenever you log in.

For DIY troubleshooting advice and repair guides, visit our repair help section.

Owner’s manual

Model diagram and schematic

SEARCH WITHIN THIS MODEL

?

This is the number corresponding to the part on the diagram / schematic

Search
ALL PARTS
Showing 10 of 91 parts  |
Samsung Leg AH62-01389B
#90

Cabinet parts diagram

Samsung leg

Part #AH62-01389B

The manufacturer no longer makes this part, and there's no substitute part

Samsung Fan Motor AH31-00039A
#NI

Cabinet parts diagram

Samsung fan motor

Part #AH31-00039A

The manufacturer no longer makes this part, and there's no substitute part

Jvc Antenna AH42-00001B
#NI

Cabinet parts diagram

Jvc antenna

Part #AH42-00001B

The manufacturer no longer makes this part, and there's no substitute part

Diode 0402-001258
#NI

Cabinet parts diagram

Diode

Part #0402-001258

The manufacturer no longer makes this part, and there's no substitute part

I/r Sensor 0609-001187
#NI

Cabinet parts diagram

I/r sensor

Part #0609-001187

The manufacturer no longer makes this part, and there's no substitute part

Rca Cable AH39-40001V
#NI

Cabinet parts diagram

Rca cable

Part #AH39-40001V

The manufacturer no longer makes this part, and there's no substitute part

Samsung Fuse 3601-000319
#NI

Cabinet parts diagram

Samsung fuse

Part #3601-000319

The manufacturer no longer makes this part, and there's no substitute part

Diode 0402-001077
#NI

Cabinet parts diagram

Diode

Part #0402-001077

The manufacturer no longer makes this part, and there's no substitute part

Samsung Integrated Circuit 1204-002080
#NI

Cabinet parts diagram

Samsung integrated circuit

Part #1204-002080

The manufacturer no longer makes this part, and there's no substitute part

Relay 3501-001008
#NI

Cabinet parts diagram

Relay

Part #3501-001008

The manufacturer no longer makes this part, and there's no substitute part
