$10.89 |
16% OFF Phone Price : $12.89
CONFIRM THE PART FITS
Downdraft Vent Blower Fan Assembly WPW10242000
Part #WPW10242000
Part Information
This blower fan assembly (part number WPW10242000) is for downdraft vents.
Blower fan assembly WPW10242000 pulls smoke and cooking odors into the vent and blows them out through the exhaust vent.
Shut off electrical power to the downdraft vent before installing this part. Wear work gloves to protect your hands.
Frequently Used Together
- $6.29 |14% OFF Phone Price : $7.29
- $21.89 |22% OFF Phone Price : $27.89
Top models using the same part
| Model Name | Model Number | Diagram Name |
|---|---|---|
| Model #KIRD801VSS1 KitchenAid downdraft ventilation system | KIRD801VSS1 | |
| Model #KIRD861VSS1 KitchenAid downdraft ventilation system | KIRD861VSS1 | |
| Model #KIRD801VSS0 KitchenAid downdraft ventilation system | KIRD801VSS0 | |
| Model #KIRD861VSS0 KitchenAid downdraft ventilation system | KIRD861VSS0 | |
| Model #KWCU405SWH0 KitchenAid range hood | KWCU405SWH0 | |
| Model #KWCU465SWH0 KitchenAid range hood | KWCU465SWH0 | |
| Model #KWCU465SBL0 KitchenAid range hood | KWCU465SBL0 | |
| Model #KICU465SSS0 KitchenAid range hood | KICU465SSS0 | |
| Model #KICU465SWH0 KitchenAid range hood | KICU465SWH0 | |
| Model #KICU465SBL0 KitchenAid range hood | KICU465SBL0 |
Reviews
Good Price, Easier Than Expected Install
As this was an expensive part for my DIY repair. I am weekend warrier type fixer and am aware of my limitations. Given the replacement part cost and the fact that there is very little on the internet showing our 10 year old Kitchenaide hood/motor replacement I was very nervous. I pulled the old malfunctioning fan and when the replacement part from Sears arrived was happy they matched exactly. I only had to remove the 3 filters and a stainless steel frame to fully gain access to the fan/motor housing and connection. An easy disconnect and the ONLY two screws on the bottom of the old fan/motor housing attached to the hood frame. Cleaned out the area of grease/dirt before pushing the round exhaust port of the new fan into the vertical duct. Held it in place (maybe another person helping will be easier) while I put both housing screws in place. Attached the wiring harness and replaced the green ground wire. Worked perfectly. Fairly easy to install and Sears Parts had the best price around for this older replacement piece.
Texas A, San Marcos, TX
Did you find this review helpful?
- Ease of Installation
- Moderate
- Duration of Installation
- 30 minutes - 1 hour
Yes, I would recommend this to a friend
