Model # NTC5075BHA1 Official ICP gas furnace

Here are the diagrams and repair parts for Official ICP NTC5075BHA1 gas furnace, as well as links to manuals and error code tables, if available.

There are a couple of ways to find the part or diagram you need:

  • Click a diagram to see the parts shown on that diagram.
  • In the search box below, enter all or part of the part number or the part’s name.

Not all parts are shown on the diagrams—those parts are labeled NI, for “not illustrated”.

We encourage you to save the model to your profile, so it’s easy to access parts and manuals for your appliance whenever you log in.

For DIY troubleshooting advice and repair guides, visit our repair help section.

Model diagram and schematic

SEARCH WITHIN THIS MODEL

?

This is the number corresponding to the part on the diagram / schematic

Search
ALL PARTS
Showing 10 of 55 parts  |
Furnace Blower Assembly 1708607
#19

Functional diagram

Furnace blower assembly

Part #1708607

Replaced by #1013833

?
Manufacturer substitution
This part replaces 1708607. Substitute parts can look different from the original.
$237.41 |
5% OFF Phone Price : $249.41
Back Order
Control Pres 1093433
#25

Functional diagram

Control pres

Part #1093433

Replaced by #1174276

?
Manufacturer substitution
This part replaces 1093433. Substitute parts can look different from the original.
$62.55 |
9% OFF Phone Price : $68.55
In Stock
Valve 1005597
#16

Functional diagram

Valve

Part #1005597

The manufacturer no longer makes this part, and there's no substitute part

Pilot Burner 1007457
#12

Functional diagram

Pilot burner

Part #1007457

The manufacturer no longer makes this part, and there's no substitute part

Burner Assembly 1054410
#13

Functional diagram

Burner assembly

Part #1054410

Replaced by #1008724

?
Manufacturer substitution
This part replaces 1054410. Substitute parts can look different from the original.
$84.88 |
7% OFF Phone Price : $90.88
In Stock
Sw Lmt T Ror 1320368
Sw lmt t ror

Part #1320368

$94.07
In Stock
Baffle 707010031
#26

Non-functional diagram

Baffle

Part #707010031

$49.47
In Stock
Rail Galv Bl 57059

#NI

All parts diagram

Rail galv bl

Part #57059

$952.55
In Stock
Panel Cutoff 721020008
#24

Non-functional diagram

Panel cutoff

Part #721020008

$252.09
In Stock
Filter Rack 741010039
#16

Non-functional diagram

Filter rack

Part #741010039

$47.60
In Stock
