Sharp
Countertop Microwave

Model # R-330BK Official Sharp microwave

Here are the diagrams and repair parts for Official Sharp R-330BK microwave, as well as links to manuals and error code tables, if available.

There are a couple of ways to find the part or diagram you need:

  • Click a diagram to see the parts shown on that diagram.
  • In the search box below, enter all or part of the part number or the part’s name.

Not all parts are shown on the diagrams—those parts are labeled NI, for “not illustrated”.

We encourage you to save the model to your profile, so it’s easy to access parts and manuals for your appliance whenever you log in.

For DIY troubleshooting advice and repair guides, visit our repair help section.

Model diagram and schematic

SEARCH WITHIN THIS MODEL

?

This is the number corresponding to the part on the diagram / schematic

Search
ALL PARTS
Showing 10 of 107 parts  |
Connector QCNCMA446DRE0

#3-01A

All parts diagram

Connector

Part #QCNCMA446DRE0

The manufacturer no longer makes this part, and there's no substitute part

Transistor VS2SB1238//-3

#NI

All parts diagram

Transistor

Part #VS2SB1238//-3

The manufacturer no longer makes this part, and there's no substitute part

Resistor VRD-B12EF472J

#NI

All parts diagram

Resistor

Part #VRD-B12EF472J

The manufacturer no longer makes this part, and there's no substitute part

Diode VHD11ES1///-1

#NI

All parts diagram

Diode

Part #VHD11ES1///-1

The manufacturer no longer makes this part, and there's no substitute part

Thermal Cu RTHM-A078WRE0

#1-04

All parts diagram

Thermal cu

Part #RTHM-A078WRE0

The manufacturer no longer makes this part, and there's no substitute part

Fuse Holder QFSHDA009WRE0

#1-02

All parts diagram

Fuse holder

Part #QFSHDA009WRE0

The manufacturer no longer makes this part, and there's no substitute part

Fan NFANJA029WRE0

#4-05

All parts diagram

Fan

Part #NFANJA029WRE0

The manufacturer no longer makes this part, and there's no substitute part

Motor RMOTDA161WRE0

#1-12

All parts diagram

Motor

Part #RMOTDA161WRE0

The manufacturer no longer makes this part, and there's no substitute part

Stopper LSTPPA139WRF0

#5-05

All parts diagram

Stopper

Part #LSTPPA139WRF0

The manufacturer no longer makes this part, and there's no substitute part

Lever MLEVPA226WRF0

#4-11

All parts diagram

Lever

Part #MLEVPA226WRF0

The manufacturer no longer makes this part, and there's no substitute part
